Clutch Assembly - 16 Spline - 5.6 Inch Bell - Yamaha Linhai 250cc 260cc 300cc - Version 20

ATV Scooter Clutch - 16 Spline - 250cc 260cc 300cc

Version 20 - Newer Version with Smaller Bell

Clutch assembly is usually used on water cooled 250cc, 260cc and 300cc Chinese manufactured brands and models. Also used on the Hart Karts with the 300cc engine. Known to fit Manco, Talon, Linhai, Buyang, Roketa, and many more.  Please measure and compare before ordering.

Clutch details:

• Bell OD: 145mm (5 5/8 in)

• Bell ID: 135mm (5.35 in)

• Bell Height: 38mm (1.5 in)

• Clutch Shoe OD: 134mm (5.25 in)

• Pulley OD:  6 7/16 inches

• Rear clutch for 250cc-300cc engine
• 16 splines inside the clutch drum/bell
• 17mm ID spline shaft
• Uses LARGER spline shaft than found on most machines
• Fits 250cc, 260cc, 300cc VOG260

Known to fit water cooled 250cc-500cc full auto with CVT tranny atvs, scooters, go karts.  Check pictures and measurements to be sure this is the correct clutch for your application.  American Sportworks 260cc, Hart Kart 300cc 500cc, Linhai 260cc 300cc, Manco Talon 260cc 300cc.
